● 1 × connector X5 (only for design W0070)
● 1 × connector X6
● 1 × connector X9 (for order codes -xxBx)
● 1 × brochure with safety instructions (in 5 languages)
5.3.4 Technical Data
Ambient and Operating Conditions
General Information
Conditions for transport and storage: see chapter 4.2 Transport and Storage,
page 19.
Installation conditions: see chapter 4.3 Installation Conditions , page 19.
This chapter contains:
● limit values for use in the scope of C-UL
● applied standards (CE conformity, UL listing)
UL Data
Ambient and operating conditions - UL ratings
Description Symbol Unit
HCS03.1E-
W0070-_-05
HCS03.1E-
W0100-_-05
HCS03.1E-
W0150-_-05
HCS03.1E-
W0210-_-05
Suitable for use on a circuit capable
of delivering not more than this
SCCR, symmetrical amperes (UL)
1)
I
SCCR
A rms 42000
rated input voltage, power (UL)
2)
U
LN_nenn
V 400...500
rated input current (UL)
3)
I
L_cont
A 50,0 80,0 106,0 146,0
maximum output voltage (UL)
U
out
V 480
maximum output current (UL)
I
out_max
A 45,0 75,0 95,0 145,0
1) 600 V AC or less, use listed AC input line fuses or listed circuit breakers
2) HMS, HMD, HLB, HLC, KCU: DC bus L+, L-; HMV, HCS: mains input
L1, L2, L3
3) at PDC_cont
Fig.5-50: HCS - Ambient and operating conditions - UL ratings
Information on Standards
Applied standards
Description Symbol Unit
HCS03.1E-
W0070-_-05
HCS03.1E-
W0100-_-05
HCS03.1E-
W0150-_-05
HCS03.1E-
W0210-_-05
listing according to UL standard
(UL)
UL 508 C
UL files (UL) E 227957
listing according to CSA standard
(UL)
Canadian National Standard(s) C22.2 No. 14-05
Fig.5-51: HCS - Applied standards
