Bosch Rexroth IndraDrive HMV - HMV - Diagnostic Command Messages

Display
Diagnostic message num‐
ber
Diagnostic message
VM F8813 F8813
Connection error mains
choke
VM F9001 F9001 Error internal function call
VM F9003 F9003 Watchdog
VM F9004 F9004 Hardware trap
Fig.10-12: Diagnostic error messages HMV
HMV - Diagnostic Command Messages
For detailed descriptions of the diagnostic messages mentioned in
this chapter, see Troubleshooting Guide of the firmware documen‐
tation.
Diagnostic command messages HMV
Display
Diagnostic message num‐
ber
Diagnostic message
VM C01 C0100
Communication phase 3
transition check
VM C0101 C0101
Invalid parameters (->
S-0-0021)
VM C0102 C0102
Limit error in parameter (->
S-0-0021)
VM C02 C0200
Exit parameterization level
procedure command
VM C0201 C0201
Invalid parameters (-
>S-0-0423)
VM C0202 C0202
Parameter limit error (-
>S-0-0423)
VM C0203 C0203
Parameter calculation error
(->S-0-0423)
VM C0212 C0212
Invalid control section data
(->S-0-0423)
VM C04 C0400
Activate parameterization
level 1 procedure com‐
mand
VM C0401 C0401 Switching not allowed
VM C05 C0500
Reset class 1 diagnostics,
error reset
VM C08 C0800
Load basic parameters
command
VM C0851 C0851
Parameter default value in‐
correct (-> S-0-0021)
VM C0852 C0852 Locked with password
Fig.10-13: Diagnostic command messages HMV
