Exemplary Data for Applications
General Information
This chapter contains examples of allowed performance profiles.
Performance Profiles
Performance Profiles of Regenera‐
tive Supply Units
The following profiles have been defined for regenerative supply units.
Profile Explanation
performance profile “WZM_HS_KB_e” The characteristic data of the profile are used to
select infeeding and regenerative supply units.
Characteristic of applications in machine tools,
short-time operation of the main spindle.
performance profile “WZM_HS_Fr_r” The characteristic data of the profile are used to
select regenerative supply units.
Characteristic of main spindles in milling ma‐
chines.
Project Planning Manual | Rexroth IndraDrive Electric Drives
and Controls
| Bosch Rexroth AG 233/369
IndraDrive M Supply Units
