Description Symbol Unit
HCS02.1E-
W0012-_-03
HCS02.1E-
W0028-_-03
HCS02.1E-
W0054-_-03
HCS02.1E-
W0070-_-03
maximum output voltage (UL)
U
out
V 530
maximum output current (UL)
I
out_max
A 4,5 11,5 22,0 28,0
1) 600 V AC or less, use listed AC input line fuses or listed circuit breakers
2) HMS, HMD, HLB, HLC, KCU: DC bus L+, L-; HMV, HCS: mains input
L1, L2, L3
3) at PDC_cont
Fig.5-13: HCS - Ambient and operating conditions - UL ratings
Information on Standards
Applied standards
Description Symbol Unit
HCS02.1E-
W0012-_-03
HCS02.1E-
W0028-_-03
HCS02.1E-
W0054-_-03
HCS02.1E-
W0070-_-03
listing according to UL standard
(UL)
UL 508 C
UL files (UL) E 134201
listing according to CSA standard
(UL)
Canadian National Standard(s) C22.2 No. 14-05
Fig.5-14: HCS - Applied standards
Project Planning Manual | Rexroth IndraDrive Electric Drives
and Controls
| Bosch Rexroth AG 35/369
Power Sections for Converters - IndraDrive C
