Description Symbol Unit
HCS02.1E-
W0012-_-03
HCS02.1E-
W0028-_-03
HCS02.1E-
W0054-_-03
HCS02.1E-
W0070-_-03
control voltage when using motor
holding brake with motor cable
length > 50 m
3)
U
N3
V 26 ± 5 %
maximum allowed voltage for 1 m
U
N3_max
V 33,00
maximum inrush current at 24V
supply
I
EIN3_max
A 2,80
pulse width of I
EIN3
t
EIN3Lade
ms 15
input capacitance
C
N3
mF 0,56
rated power consumption control
voltage input at U
N3
(UL)
4)
P
N3
W 12 14 23
1) 2) 3) observe supply voltage for motor holding brakes
4) HMS, HMD, HCS: plus holding brake and control section; KCU01: at
max. number of axes; KSM01: plus holding brake (UN x IN)
Fig.5-23: HCS - Data for control voltage supply
Mains Voltage
Data for mains voltage supply
Description Symbol Unit
HCS02.1E-
W0012-_-03
HCS02.1E-
W0028-_-03
HCS02.1E-
W0054-_-03
HCS02.1E-
W0070-_-03
input frequency (UL)
f
LN
Hz 50...60
tolerance input frequency (UL) Hz ± 2
maximum allowed mains frequen‐
cy change
Δf
LN
/Δt
Hz/s -
rotary field condition none
Suitable for use on a circuit capable
of delivering not more than this
SCCR, symmetrical amperes (UL)
1)
I
SCCR
A rms 42000
nominal mains voltage
U
LN_nenn
V 3 AC 400
mains voltage single-phase
U
LN
V 200...250
mains voltage three-phase at TN S,
TN C, TT mains
U
LN
V 200...500
mains voltage three-phase at IT
mains
2)
U
LN
V 200...500
mains voltage three-phase at Cor‐
ner-grounded-Delta mains
3)
U
LN
V 200...500
tolerance U
LN
(UL)
% ± 10
minimum inductance of the mains
supply (inductance of mains
phase)
4)
L
min
µH 40
assigned type of mains choke
HNL01.1E-1000-N0012-A-500-
NNNN
HNL01.1E-100
0-N0020-
A-500-NNNN
HNL01.1E-060
0-N0032-
A-500-NNNN
Project Planning Manual | Rexroth IndraDrive Electric Drives
and Controls
| Bosch Rexroth AG 43/369
Power Sections for Converters - IndraDrive C
