Usage
Type Usage
HCS03.1E-Wxxxx-NNNV
HCS03.1E-Wxxxx-NNBV
Operation of a three-phase a.c. motor
(asynchronous or synchronous motor).
HCS03.1E-Wxxxx-LNNV
HCS03.1E-Wxxxx-LNBV
blower control depending on load
Applications with operation at partial load
and requirement of a low degree of noise
development.
Fig.5-43: Usage of HCS03
Structure, Block Diagrams
1 power section
2 control section
Fig.5-44: Basic structure of the drive controller
Project Planning Manual | Rexroth IndraDrive Electric Drives
and Controls
| Bosch Rexroth AG 63/369
Power Sections for Converters - IndraDrive C
