Solution 6000-IP
4
Bosch Security Systems 10/22 BLCC615R
Quick Start Guide
Features
Listed below are the main features of the Solution 6000-IP
Control Panel.
Individual Box Tamper Circuit Monitoring
Daylight Savings
Senior Watch
GSM/GPRS/Ethernet Reporting Options
System Maintenance Interval Reminder
System Weekly Test Reminder
Area Inactivity Interval
Up to 16 Access Doors
Temporary PIN
Dual Reporting
Dual Redundant Reporting
Alarm Report Abort/Cancel Options
8 Programmable Holiday Calendars
16 Programmable TimeZones
8 On-board Zones (Single EOL) / 16 On-Board Zones
(Dual EOL)
Expandable To 144 Zones)
Fire Alarm Verification
990 PIN Users
4 Supervised High Power Digital Outputs
1 Relay 2 Amp Form (C) Contact (Expandable to 32)
Supervised Siren Driver
Partitionable To 8 Areas
Supervised LAN Keypads (Maximum 16 Keypads)
Keyswitch Input
2000 History Event Memory
EMI / Lightning Transient Protection
Fully Menu Text Programmable
Programmable Via Solution Link Software (Remote/
Direct)
TimeZone Executed Functions
60+ Output Event Types
Exit Restart
Expansion Module Supervision
Remote Arming
Fingerprint Reader Options
Site Manager End User Management Software
Macro Functions
Overview
Zones
The Solution 6000-IP control panel provides up to 144
separate zones of protection. Zone programming
determines the panel’s response to open/short and tamper
conditions on the zone loop.
Areas
The control panel supports up to 8 separate areas. You can
assign all zones to a single area, or you can assign each
zone to a combination of different areas.
You can arm and disarm the control panel by area,
alternatively, you can arm and disarm several areas at the
same time.
Keypads
You can connect a maximum of 16 fully supervised keypads
to the control panel. The available current affects the total
number of keypads that you can connect without the need
to provide additional power supplies.
History Log
The control panel can store up to 2000 history events from
all 8 areas. All events are stored in the log, even if they are
programmed not to report via the on-board dialler.
You can view the control panel’s history log via keypad,
or by connection of a personal computer (direct/remote)
using the SolutionLink upload/download software.
Programming
You can program the Solution 6000-IP either by a keypad or
using a personal computer using the Solution Link upload/
download software.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Bosch Solution 6000-IP CC615GWF and is the answer not in the manual?

Bosch Solution 6000-IP CC615GWF Specifications

General IconGeneral
Battery BackupYes
Wireless SupportYes
Remote AccessYes, via mobile app and web browser
CommunicationIP, GSM
Mobile App SupportYes
System TypeHybrid
IP ConnectivityYes
Compatible withBosch
InstallationProfessional installation
