Brady M210 User Manual

M210/M210-LAB User Manual 56
WireMarker Label Type (M210)
The WireMarker label type is designed to repeat entered data down the length of the label. The data
repeats as many times as possible, considering the font size and the wire size selected.
All media, except Permasleeve, support WireMarker label types.
To use the WireMarker label type:
1. Press LABEL TYPE.
2. Using navigation keys, choose WireMarker, then press Enter .
3. Navigate to the appropriate label size to fit the intended wire, then press Enter.
Note: Size is automatically determined when using pre-sized labels and is displayed in the lower
left corner of the screen (examples: W.75, W1.5, W2.0)
4. Enter the data you want repeated down the length of the label.
Note: The repeated data does not display on the screen, but displays on printout.
5. Press Enter to start a new line of text.
When the label is printed, both lines of text are repeated down the label, depending on the size
of the label and font.
WireMarker label type - text on screen WireMarker label type - printed text

Brady M210 Specifications

General

Product color	Black, Yellow
Internal memory	16 MB
Built-in barcodes	Code 39, Data Matrix, QR Code
Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum printing width	16 mm
Battery type	Built-in battery
AC input voltage	110 - 240 V
Maximum label width	19.05 mm
USB port	-
Connectivity technology	Wireless

Weight and Dimensions

Depth	63 mm
Width	114 mm
Height	241 mm
Weight	750 g
