CHAPTER 4 TRANSMISSION
3015R(h)/3515R(h)/4015R(h)/F36R(h)/F42R(h) TRACTOR
1. OVERVIEW
1.1 SPECIFICATION
ITEM SPECIFICATION
Transmissionsystem
MEC.
MODEL
Shuttletype Mechanical,synchromesh
Mainshift 4speeds,synchromesh
Rangeshift 3speeds,constant-mesh
Shiftinggear
and
drivingspeed
F12 X R12
7 - 16
11.2 - 24
Forwarddriving:1.2-22.6km/h(0.746-14.044MPH)
Reversedriving:1.1-21.5km/h(0.684-13.360MPH)
8 - 16
12.4 - 24
Forwarddriving:1.2-23.7km/h(0.746-14.727MPH)
Reversedriving:1.2-22.5km/h(0.746-13.982MPH)
HST
MODEL
Shuttletype Hydrostatic
Mainshift
HST
Rangeshift 3speeds,constant-mesh
Shiftinggear
and
drivingspeed
CVT
7 - 16
11.2 - 24
Forwarddriving:0-29.27km/h(0-18.18MPH)
Reversedriving:0-29.27km/h(0-18.18MPH)
8 - 16
12.4 - 24
Forwarddriving:0-30.7km/h(0-30.7MPH)
Reversedriving:0-30.7km/h(0-30.7MPH)
PTOshift
Type IndependentPTO
Stage 2
Revolution
1st:560rpm 2nd:780rpm
PTOshaft Ø35mm,6splines
Rearaxle Reductionratio:
6
37
x
16
65
= 0.03992
Brake
Mainbrake Wetmulti-plateclutch
Parkingbrake
3015R(h)/3515R(h)/4015R(h):Footbrakelevertype
F36R(h)/F42R(h):Handbrake
Transmissionuid
Capacity
MEC.MODEL:34ℓ(8.98u.s.gal),
HSTMODEL:37ℓ(9.77u.s.gal)
Specication TF 500
