CHAPTER 1 GENERAL INFORMATION3015R(h)/3515R(h)/4015R(h)/F36R(h)/F42R(h) TRACTOR
1
7.2 MAJOR SPECIFICATIONS
MAJOR ITEMS 3015R(h) 3515R(h)/F36R(h) 4015R(h)/F42R(h)
Engine
Model A1700N5 A1700N4 A1700T2
Type
Vertical, water cooled 4-cycle, diesel engine
Emission regulation Final Tier4 Final Tier4 / Stage
Ⅲ��
Final Tier4 / Stage
Ⅲ��
Number of cylinders 3
Bore and stroke mm (in.) 88 X 94 (3.46 X 3.70)
Total displacement

cc (in
3
) 1,714 (104.59) (104.59)(104.59)
Rated speed

(rpm) 2,600
Power at rated engine rpm

kW(HP) 22(30) 25.7(35) 29.4(40)
Intake type Naturally Naturally Turbo
Battery

(V) 12
Fuel Diesel
Capacity
Fuel tank

ℓ(u.s.gal) 27 (7.13)
Engine crankcase

ℓ(u.s.gal) 4.3 (1.14)
Coolant

ℓ(u.s.gal) 5.0 (1.32)
Transmission case

ℓ(u.s.gal) MEC.MODEL:34(8.98),HSTMODEL:37(9.77)
Front axle

ℓ(u.s.gal) 6.4 (1.69)
Dimension
Overall length mm (in.)
(with F/weight)
3,426 (134.88)
Overall width mm (in.) 1,431 (56.34) 1,451 (57.13)
Overall height mm (in.) 2,614 (102.9) 2,643 (104.06)
Wheel base mm (in.) 1,671 (65.79)
Min. ground clearance mm (in.) 306 (12.05) 335 (13.19)
Tread
Front
mm (in.) 1,151 (45.31) 1,201 (47.28)
Rear mm (in.) 1,151 (45.31) 1,165 (45.87)
Transmission
Tire size
Front wheel 7.0-16 6PR 8.0-16 6PR
Rear wheel 11.2-24 6PR 12.4-24 6PR
Clutch MEC.MODEL:Drysingleplateclutch,HSTMODEL:N/A
Steering system Fully hydraulic
Transmission system MEC.MODEL:Synchroshuttle,HSTMODEL:HST
Brake system
Driving Wet disc type
Parking
3015R(h), 3515R(h), 4015R(h): Foot brake lever type
F36R(h), F42R(h): Hand brake lever type

Branson 4015r Specifications

General

Brand	Branson
Model	4015r
Category	Tractor
Language	English
