Branson 4015r - Brake Pedal

4
-
45
42hW-201601
CHAPTER 4 TRANSMISSION
4
3015R(h)/3515R(h)/4015R(h)/F36R(h)/F42R(h) TRACTOR
4.16 BRAKE PEDAL















%5$.(6:,7&+
F42W416A
 (1)Brakerodass’y
 (2)Brakeshaftass’y
 (3)O-ring
 (4)Drybush
 (5)Brakepedal
 (6)Springpin
 (7)Springpin
 (8)Brakepedal
 (9)Returnspring
 (10)Washer
 (11)Snapring
 (12)Rubberstopper
 (13)Pin
 (14)Snappin
 (15)Stoplampswitch
COMPONENTS
MEC. MODEL
