CHAPTER 4 TRANSMISSION 3015R(h)/3515R(h)/4015R(h)/F36R(h)/F42R(h) TRACTOR
POWER TRANSFER
HIGH SPEED (H) (H)
 Rangeshiftdriveshaft(1)→26Tgear(2)→29Tgear(3)→Rangeshiftdrivegearshaft(4)→36Tgear(5)
→20Tgear(8)→36Trangeshiftdrivengear2nd(7)→Countershaft(9)
▶
LOW SPEED (L)
 Rangeshiftdriveshaft(1)→26Tgear(2)→29Tgear(3)→Rangeshiftdrivegearshaft(4)→18Tgear
→52Tgear(6)→36Trangeshiftdrivengear2nd(7)→Countershaft(9)
▶
MID SPEED (M)
 Rangeshiftdriveshaft(1)→26Tgear(2)→29Tgear(3)→Rangeshiftdrivegearshaft(4)→34Tgear
→36Trangeshiftdrivengear2nd(7)→Countershaft(9)
▶
