100 1019572 REV. 03
Purple (Al), Ratio 1:0.6 101-149-087
Solid Mount Boosters - 40 kHz (Same as XL: 8mm)
Black (Ti), Ratio 1:2.5 109-041-174
Silver (Ti), Ratio 1:2.0 109-041-175
Gold (Ti), Ratio 1:1.5 109-041-176
Green (Ti), Ratio 1:1.0 109-041-177
Purple (Ti), Ratio 1:0.6 109-041-178
Table 7.3 Spare Parts List for the Actuator
Description EDP Number
Linear Encoder Assembly 100-143-161
RF Harness Assembly 100-246-1282
RF Contact Block Assembly 100-246-909
S-Beam Assembly 100-246-1276
Cooling Valve Assembly 100-246-896
Solenoid Valve 100-246-901
Downspeed Control Assembly (Flow Control 1 1/2 - 2" cyl) 100-246-1310
Downspeed Control Assembly (Flow Control 2 1/2 - 3" cyl) 100-246-1309
Interface Board Assembly 102-242-717R
ULS Cable Assembly 100-241-181
Power Light Harness Assembly 100-246-924
Carriage 2000X Series 100-018-039
Assy Cylinder AED/AOD - 1.5” Diameter 100-246-1729
Assy Cylinder AED/AOD - 2.0” Diameter 100-246-858
Assy Cylinder AED/AOD - 2.5” Diameter 100-246-576
Assy Cylinder AED/AOD - 3.0” Diameter 100-246-573
Assy Cylinder AED/AOD - 3.25” Diameter 149-088-859
Door (Metal) 100-037-035
Cover AE/AED Actuator, Right 100-032-473
Cover AE/AED Actuator, Left 100-032-474
Table 7.2 Accessories List for 2000X aed Actuator
Description EDP Number
