4.3 Take Inventory of Small Parts
4.3.1 Cables
Two cables connect the power supply and actuator: the actuator interface cable, and the
RF cable. If the system is to be automated, you may also need a J911 start cable and a
user I/O cable. Check your invoice for cable types and cable lengths.
Table 4.1 Small Parts included (=x) with Power Supply and/or Actuator Assemblies
Part or Kit
2000X Power Supply Actuator
15
kHz
20
kHz
30
kHz
40
kHz
Stand
(Base)
Stand
(Hub)
(alone)
T-Handle Wrench x x x
Mylar Washer Kit x x x
Silicone Grease x
Actuator Mtg. Bolts x
15 kHz Spanners (2)
x
20 kHz Spanners (2)
x
30 kHz Spanners (2)
x
40 kHz Spanners (2)
x
40 kHz Sleeve ordered part ordered part ordered part
40 kHz Sleeve
Spanner
ships w/
Sleeve
ships w/
Sleeve
ships w/
Sleeve
Fixture Bolts and
Washer
x
M8 Allen Wrench x
Table 4.2 List of Cables
EDP Description
101-241-202 Remote Pneumatic (RP) Package Cable (J924), 8’
101-241-203 Actuator Interface, 8’ (J925S)
101-241-204 Actuator Interface, 15’ (J925S)
101-241-205 Actuator Interface, 25’ (J925S)
101-241-206 Actuator Interface, 50’ (J925S)
101-241-207 Alarm I/O, 8’ (J957S)
101-241-208 Alarm I/O, 15’ (J957S)
101-241-209 Alarm I/O, 25’ (J957S)
