1019572 REV. 03 103
Spring, Compression 890-048-030R
Washer, Flat 890-057-040R
Nut Mtg Mech Stop 580-173-082R
Nut Lock Mech Stop 580-173-083R
Knob Mech Stop 580-263-005R
Bumper Shock Absorber 100-013-019
Scr Set M8X60 580-177-127R
Spring Carriage Ext 580-048-025R
ASSY REGULATOR, SEMI-PRECISION 149-246-1560
Assy Gauge 100-246-554
ULS Switch Optical 200-099-190R
Table 7.6 Suggested Spares
Assembly EDP # 1 - 4 Units 6 - 12 Units 14 + Units
RF Harness 100-246-1282 0 1 2
RF Connector 100-246-932 0 0 1
Linear Encoder 100-143-161 0 0 1
Carriage Door 100-037-035 0 0 0
Door Screw 100-298-242 0 0 2
Contact Block 100-246-909 1 1 2
Ground Spring 100-095-024 0 0 1
2000X AED Interface
Board
102-242-717R 0 0 1
aed/aod Interface Kit 101-063-814
ULS Switch 200-099-190R 0 1 2
Air Cylinder, 3.0" 100-246-573 0 1 1
Solenoid Valve 100-246-901 1 1 2
S-Beam 100-246-1276 0 0 1
Cooling Valve 100-246-896 1 2 4
Power Light 100-246-924 0 1 1
ULS Cable 100-241-181 0 1 1
D Shell Kit 200-063-195R 0 1 1
Table 7.5 Spare Parts List for the 2000X aed 15 kHz Actuator
Description EDP Number
