4.4 Installation Requirements
4.4.1 Location
The actuator or stand may be installed in a variety of positions. The stand (on a base) is
often manually operated, using its base-mounted start switches, and so is installed at a
safe and comfortable workbench height (approximately 30-36 inches) with the operator
sitting or standing in front of the system. Stands (on hubs) are often used in automated
systems and may be manually or automatically loaded and unloaded. Actuators alone can
be mounted in any orientation, Contact Branson if mounting upside down.
The power supply may be located up to 25 feet away for the 15 kHz, (50' for 20 kHz, 20'
for 30 kHz, and 15' for 40 kHz models) from the actuator. The power supply must be
accessible for user parameter changes and settings, and must be placed in a horizontal
orientation. The power supply should be positioned so it does not draw in dust, dirt or
material via its rear fans. Refer to the illustrations on the pages that follow for a
dimensional drawing of each component. All dimensions are approximate and may vary
between models:
Figure 4.6
Power Supply Dimensional Drawing
Figure 4.7 2000X Actuator Dimensional Drawing
Figure 4.8 2000X aed 15 kHz Actuator Dimensional Drawing
4.4.2 Environmental Specifications
WARNING
The stand may tip over if moved around the axis of its column, if not
properly secured. The work surface on which a stand is installed must
be sturdy enough to support it, and secure enough to not tip over
when the stand is adjusted during installation or setup.
Table 4.3 Environmental Specifications
Environmental Concern Acceptable Range
Humidity Maximum 95%, non-condensing
Operating Altitude Up to 6560 ft (2000 m)
Ambient Operating Temperature +5°C to +50°C (41°F to 122°F)
Storage / Shipping Temperature
-25°C to +55°C (-13°F to +131°F);
Up to +70°C (+158°F) for 24 hours
