40 1019572 REV. 03
4.2.4 Stand (Actuator on a Hub)
Figure 4.4 Unpacking the Stand (Actuator on a Hub); Hub Shown Separately
1. Move the shipping container close to the intended installation location, leave it on the floor.
2. Cut the two vertical packing straps, and open the top of the box. Remove the insert from the top
of the box. Set the insert box aside.
3. Remove the staples at the bottom of the protective box. Lift the protective box off the pallet.
Flatten the box and lay it next to the pallet (you will lay the stand on it soon).
CAUTION
Heed the “This End Up” arrows and the “Open Top First” instructions.
The packaging is designed to be removed from the assemblies from
an upright orientation only.
CAUTION
The unit may tend to tip over. Stabilize the stand using the lifting
hook or an assistant.
