Branson Emerson 2000X aed - Table 7.5 Spare Parts List for the 2000 X Aed 15 Khz Actuator

102 1019572 REV. 03
Boosters - 15 kHz
Black (Ti), Ratio 1:2.5 101-149-099
Silver (Ti), Ratio 1:2 101-149-098
Gold (Ti), Ratio 1:1.5 101-149-097
Green (Ti), Ratio 1:1 101-149-096
Purple (Ti), Ratio 1:0.6 101-149-095
Gold (Al), Ratio 1:1.5 101-149-080
Green (Al), Ratio 1:1 101-149-079
Purple (Al), Ratio 1:0.6 101-149-087
Table 7.5 Spare Parts List for the 2000X aed 15 kHz Actuator
Description EDP Number
Linear Encoder Assembly 100-143-161
RF Harness Assembly 560-257-230R
S-Beam Assembly 100-246-1276
Cooling Valve Assembly 100-246-896
Base Assembly 560-056-042R
Act-support Assembly (China) 560-164-006R
Act-support Assembly (Brookfield) 149-246-1422
Solenoid Valve 100-246-901
Downspeed Control Assembly (Flow Control 1 1/2-2” cyl) 100-246-1310
Downspeed Control Assembly (Flow Control 2 1/2-3” cyl) 100-246-1309
Interface Board Assembly 102-242-717R
ULS Cable Assembly 560-257-232R
Power Light Harness Assembly 560-257-233R
Carriage/Door, 2000X 15 kHz 580-121-056R
Assy Cylinder AED– 3.0” Diameter 560-198-009R
Cover AE/AED Actuator, Right 580-101-181R
Cover AE/AED Actuator, Left 580-101-180R
Rod Mech Stop 580-221-005R
Block Mech Stop 580-081-060R
Table 7.4 Accessories List for 2000X aed 15 kHz Actuator
Description EDP Number
