Description of the device
5.3 Display and control elements
1 2 3 4 5 6 9 107 8
No. Element Function
1
On/o key:
Switches the device on and o
2
Status display
Green LED: Delivery
Red LED: Technical alarm, operating alarm
3
Arrow keys:
Q
Scroll through menus
Q
Change settings
Q
Answer yes/no questions
Q
Select scale values and change between digits when
inputting values
Q
Open a function while the infusion is ongoing
or suspended
4
OK key:
Q
Select/conrm function
Q
Conrm value/settings/input/alarms
