Router modules
1
Installation considerations
When you install NI-MLX-10Gx8-M or NI-MLX-10Gx8-D modules, you must upgrade the software on
all interface modules and management modules to the appropriate software release. Refer to the
Hardware Installation Notes that shipped with the interface module.
NI-MLX-10Gx8-D modules do not support Multiprotocol Label Switching (MPLS).
If you try to configure MPLS on a device that has NI MLX 8x10G -D modules installed, you will see
the following error message.
Brocade(config)# router mpls
The command can't be used when system contains -d class modules.
If you install an NI-MLX-10Gx8-D module in a device that is running MPLS, the NI-MLX-10Gx8-D
module boots in INTERACTIVE mode, and the following error message is displayed.
Brocade#
Module is inserted into slot 7
SYSLOG: May 28 16:22:35:<13May 28 16:22:35 System: Module was inserted to slot 7
Module 7 is -d class, it can't work when router mpls is enabled.
Reset slot 7
SYSLOG: May 28 16:22:48 :<13>May 28 16:22:48 Module 7 is reset by mgmt (reason:
boot to interactive mode)
Power supply requirements for NI-MLX-10Gx8-M and NI-MLX-10Gx8-D modules
For power supply requirements for NI-MLX-10Gx8-M and NI-MLX-10Gx8-D modules, refer to
Chapter 7, “Hardware Specifications”.
24-port 1 Gbps Ethernet copper RJ45 interface module
The 24-port 1 Gbps Ethernet copper interface module is available in the following formats:
• BR-MLX-1GCx24-X-ML
• BR-MLX-1GCx24-X
This module has 32 Mb of flash memory and contains 24 RJ45 physical ports, through which you
can connect your router to other network routers. BR-MLX-1GCx24-X-ML support s up to 512K IPv4
routes in hardware and BR-MLX-1GCx24-X version supports up to 1M IPv4 routes in hardware.
BR-MLX-1GCx24-X-ML does not include a software license, but can be upgraded to an X version
through a software license. Please contact Brocade to purchase the license upgrade.
TABLE 9 NI-MLX-10Gx8-M and NI-MLX-10Gx8-D interface module LEDs
LED Location State Meaning
Power Lower left corner of module Green Module is receiving power
Off Module is not receiving power
Link/Activity Underneath the ports. Top port LED
on left, bottom port LED on right.
Green
blinking
Port enabled and link is up.
Off Port is disabled.
