Brother DCP-L5600DN Service Manual

2-32
Confidential
Size Mismatch Reload correct paper. Detected that the size of paper set
in the paper tray was over 10 mm
shorter than letter size during
receiving fax data or printing a list
or report.
8E02 2-66
Reload correct paper
in MP Tray, then press
[Retry].
When printing from the MP tray,
the size of paper set in the MP tray
does not match the size specified
by the driver.
9001 2-67
Reload correct paper
in Tray1, then press
[Retry].
When printing from the paper tray
1, the size of paper set in the
paper tray 1 does not match the
size specified by the driver.
9002 2-67
Reload correct paper
in Tray2, then press
[Retry].
When printing from the paper tray
2, the size of paper set in the
paper tray 2 does not match the
size specified by the driver.
9003 2-67
Reload correct paper
in Tray3, then press
[Retry].
When printing from the paper tray
3, the size of paper set in the
paper tray 3 does not match the
size specified by the driver.
9004 2-67
Reload correct paper
in Tray4, then press
[Retry].
When printing from the paper tray
4, the size of paper set in the
paper tray 4 does not match the
size specified by the driver.
9005 2-67
Reload correct paper
in Tray5, then press
[Retry].
When printing from the paper tray
5, the size of paper set in the
paper tray 5 does not match the
size specified by the driver.
9006 2-67
Supplies Toner Low Dot counter or develop roller
counter of the toner is reaching
the upper limit.
4B01 2-45
Drum End Soon. The number of rotations of the
drum unit is reaching the upper
limit.
4000 2-44
Replace Drum The number of rotations of the
drum unit has reached the upper
limit. (Printing does not stop.)
4200 2-44
Too Many Trays Turn the power off and
remove additional
trays.
Detected more LTs than
connectible limit. 6D00 2-50
Touchscreen
initialization failed
Remove any material
which is on the
touchscreen.
An error occurred while initializing
the touch panel. D800 2-79
Unable to
Update:**
Check the firmware
update file and try
again.
Cannot execute USB Memory
Firm UPDATE. --- 4.14.2
Error message
Description
Error
codes
Refer
to:
First line Second line

Brother DCP-L5600DN Specifications

General

Type	all in one
Color	black/gray, multi
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	50
Output Tray Capacity	150 sheets
Automatic Document Feeder Capacity	70 sheets
Paper Size	ansi a, legal, executive, a4, a5, a6, folio
Paper Handling	letter, legal, executive, a4, a5, a6, envelopes, custom sizes (3.0-8.5" (w), 5.0-14" (l))
Paper Weight	60 grams per square meter
Printing Method	monochromatic
Color Print Speed	0 pages per minute
Mono Print Speed	42 pages per minute
First Page Print Time	7 seconds
Print Resolution Mono	up to 1200 x 1200
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 50, 000
Reduction and Enlargement	no
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 1200 x 1200
Duplex Scan	yes
Max Copies	99
Copier Resolution Mono	up to 1200 x 600
Fax Function	no
Cartridges	brother tn820, brother tn850
Number Of Cartridges	1
Internal Memory	yes
Memory Card	no
Network	wired
Connectivity	usb 2.0, ethernet
Mobile Devices Connection	no

Weight and Dimensions

Depth	16.8 inches
Height	16.8 inches
Width	19.5 inches
Net Weight	37.7 pounds
