3-12
Confidential
3 Develop Release Motor
4 Front Cover Sensor
Develop release motor
Panel cable rack
Engine PCB ASSY
Hook
CN20
Front
Panel cable rack
Hook
Hook
Engine PCB ASSY
CN14
Front
Front cover sensor
