■ Error code 84
Paper jam at the rear section of the printer.
<User Check>
- Check if the paper is jammed. If jammed, remove it.
Jam Rear
Open the Back Cover and remove the jammed paper.
Step Cause Remedy
1 Foreign object around paper
eject
Remove the foreign object.
2 Coming off of back flapper ASSY Re-assemble the back flapper ASSY.
3 Paper eject actuator
malfunction
Re-assemble the paper eject actuator.
4 Harness connection failure of
paper eject motor
Check the harness connection of the
paper eject motor and reconnect it.
5 Paper eject sensor PCB ASSY
failure
Check the sensor performance following
the procedure described in “Function code
32”. If any problem occurs, replace the
paper eject sensor PCB ASSY.
6 Paper eject motor failure Replace the paper eject motor.
7 Paper eject ASSY failure Replace the paper eject ASSY.
8 Engine PCB failure Replace the engine PCB ASSY.
9 Main PCB failure Replace the main PCB ASSY.
