3-27
Confidential
(5) Remove the Back cover stopper arm L and R from the Back cover.
Fig. 3-8
Back cover
Back cover
stopper arm L
Back cover
stopper arm R
5a
5a
5b
5b
Back cover
Back cover stopper arm R
Center
