5. LUBRICATION
PG1.5: MOLYKOTE PG-661 (W) (1.5 mm dia. ball)
The kind of the lubricating oil
(Maker name)
Lubrication point Quantity of lubrication
MOLYKOTE PG-661 (W)
(Dow Corning)
PF plate ASSY 1.5 mm dia. ball
Front cover arm L 1.5 mm dia. ball
Front cover arm R 1.5 mm dia. ball
PG1.5
PG1.5
PG1.5
PG1.5
PF plate ASSY
PF cleaner drive ASSY
