1.4.9 LAN connection status display (Function code 33)
<Function>
This function allows you to check the status of the wired LAN connection. The display items
are shown in the table below.
<Operating procedure>
(1) Press the or button to display “MAINTENANCE 33” on the LCD in the initial state of
the maintenance mode. Then, press the OK button.
(2) The display items in the table above are displayed.
(3) Press the Cancel button to return to the printer to the initial state of the maintenance
mode.
LCD LAN connection status
Active 100B-FD 100B-FD
Active 100B-HD 100B-HD
Active 10B-FD 10B-FD
Active 10B-HD 10B-HD
Inactive Not connected.
