5-25

Confidential

1.4.13 Continuous print test (Function code 67)

This function allows you to conduct the pick-up and delivery test as printing patterns.

(1) Press the or button to display “MAINTENANCE 67” on the LCD in the initial state of

the maintenance mode. Then, press the OK button.

(2) When “SELECT: K 100%” is displayed on the LCD, select a relevant continuous print

pattern using or button and then press the OK button.

The available continuous print patterns are shown below.

* KCMY1% and KCMY5% are available only for A4 and Letter.

(3) When “SELECT: A4” is displayed on the LCD, select a relevant paper size using

or button, and then press the OK button.

The available paper sizes are shown below.

LCD

SELECT: K 100%

SELECT: C 100%

SELECT: M 100%

SELECT: Y 100%

SELECT: R 100%

SELECT: G 100%

SELECT: B 100%

SELECT: KCMY1%*

SELECT: KCMY5%*

SELECT: Lattice

LCD

SELECT: A4

SELECT: LETTER

SELECT: LEGAL

SELECT: A5

SELECT: B6

SELECT: A6
