9.25 Drum Drive Motor
(1) Remove the two Drum coupling gear Z52 from the Top drive ASSY.
Fig. 3-83
Gear position: Refer to “ Top drive ASSY.”
(2) Remove the two Drum idle gear Z64 from the Top drive ASSY.
Fig. 3-84
Gear position: Refer to “ Top drive ASSY.”
Top drive ASSY
Drum coupling gear Z52
Drum coupling gear Z52
Drum idle gear Z64
Top drive ASSY
