1.3 List of Maintenance-mode Functions
*The functions shaded in the table above are user-accessible.
Function code Function Refer to:
01 EEPROM parameter initialization 1.4.1(5-3)
09 Monochrome image quality test pattern 1.4.2(5-4)
10 Worker switch (WSW) setting 1.4.3 [1](5-5)
11 Printout of worker switch (WSW) data 1.4.3 [2](5-7)
12 Operational check of LCD 1.4.4(5-8)
13 Operational check of control panel button 1.4.5(5-9)
25 Software version check 1.4.6(5-10)
28 “One Push Demo” setting 1.4.7(5-11)
32 Operational check of sensors 1.4.8(5-12)
33 LAN connection status display 1.4.9(5-15)
40 Printout of EEPROM log 1.4.10(5-16)
45 Not-disclosed-to-users functions 1.4.11(5-17)
66 Adjustment of inter-color position alignment 1.4.12(5-21)
67 Continuous print test 1.4.13(5-25)
68 Laser unit test pattern print 1.4.14(5-28)
69 Frame pattern print (One-sided) 1.4.15(5-29)
70 Frame pattern print (Two-sided) 1.4.16(5-31)
71 Color test pattern 1.4.17(5-33)
72 Sensitivity adjustment of density sensor 1.4.18(5-35)
74 Setting by country 1.4.19(5-36)
75 Sensitivity adjustment of registration mark sensor
and check of belt unit surface
1.4.20(5-38)
77 Printout of maintenance information 1.4.21(5-40)
78 Operational check of fans 1.4.22(5-42)
80 Display of machine history (log) 1.4.23(5-43)
82 Error code indication 1.4.24(5-47)
83 Developing bias voltage correction 1.4.25(5-48)
91 EEPROM parameter initialization 1.4.1(5-3)
99 Exit from the maintenance mode 1.4.26(5-49)
