Brother MFC-9125CN Service Manual

App.1-1
Confidential
WORKER SWITCH (WSW)
This appendix describes the functions of the worker switches.
It is not allowed to access all of those selectors, but it is allowed to access the selectors shaded in
the worker switch table.
■ Worker switch
WSW No. Function Refer to:
WSW01 Dial pulse setting App. 1-4
WSW02 Tone signal setting App. 1-5
WSW03 PABX mode setting App. 1-6
WSW04 Transfer facility setting App. 1-7
WSW05 1st dial tone and busy tone detection App. 1-8
WSW06 Redial/Pause button setting and 2nd dial tone detection App. 1-9
WSW07 Dial tone setting 1 App. 1-11
WSW08 Dial tone setting 2 App. 1-12
WSW09 Protocol definition 1 App. 1-13
WSW10 Protocol definition 2 App. 1-14
WSW11 Busy tone setting App. 1-15
WSW12 Signal detection condition setting App. 1-16
WSW13 Modem setting App. 1-17
WSW14 AUTO ANS facility setting App. 1-18
WSW15 Redial facility setting App. 1-19
WSW16 Function setting 1 App. 1-19
WSW17 Function setting 2 App. 1-20
WSW18 Function setting 3 App. 1-21
WSW19 Transmission speed setting App. 1-22
WSW20 Overseas communications mode setting App. 1-23
WSW21 TAD setting 1 App. 1-24
WSW22 ECM and call waiting caller ID App. 1-24
WSW23 Communications setting App. 1-25
WSW24 TAD setting 2 App. 1-26
WSW25 TAD setting 3 App. 1-26
WSW26 Function setting 4 App. 1-27
WSW27 Function setting 5 App. 1-28

Brother MFC-9125CN Specifications

General

DVD/CD printing	No
Print technology	LED
Maximum resolution	2400 x 600 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	19 ppm
Fax compatibility	ITU-T G3
Dimensions (WxDxH)	429.3 x 490.2 x 398.8 mm
All-in-one functions	Copy, Fax, Print, Scan
Connectivity technology	Wired
Color all-in-one functions	copy, fax, print, scan
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	25000 pages per month
Number of print cartridges	4
Page description languages	BR-Script 3, PCL 6
Copier resize	25 - 400 %
Maximum copy resolution	- DPI
Maximum number of copies	35 copies
N-in-1 copy function (N=)	2, 4
Copy speed (black, normal quality, A4)	19 cpm
Scan to	CIFS, E-mail, File, FTP, Image, OCR
Scanner type	Flatbed scanner
Input color depth	48 bit
Maximum scan area	A4 / Letter (216 x 297) mm
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	1200 x 2400 DPI
Fax memory	600 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, JPEG, MH, MMR (Fax coding method), MR
Fax transmission speed	2 sec/page
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	1 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Display	LCD
Market positioning	Business
Direct printing	-
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and ServerTELNET Server, HTTP/HTTPS server, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, WebServicesPrint, CIFS Client, SNTP, SSL/TLS
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Client and Server, TELNET Server, HTTP/HTTPS server, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, WebServicesPrint, CIFS Client, SNTP, SSL/TLS
Maximum internal memory	576 MB
Sound power level (standby)	30 dB
Sound pressure level (copying)	53 dB
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (off)	11 W
Power consumption (PowerSave)	75 W
Power consumption (average operating)	480 W
Package weight	28490 g
Operating relative humidity (H-H)	20 - 80 %
