31II-
Fig. 17 is displayed when depressed “ ” key to feed the tape. “3” is displayed after
completed the feed.
Fig. 17
Shifts to “28.2.5 PRINT 1 Mode” when depressed “ ” key. (Fig. 18 Display)
9.2.5. PRINT 1 Mode “5” Key
Here, check the print quality, tape length accuracy and print length accuracy.
Display of Fig. 18 is indicated when depressed “ ” key or depressed “5” key in the display
of Fig. 17 (except while in the Key Inspection Mode).
Fig. 18
The printing is started when depressed “ ” key. (Fig. 18 Display)
Initialize all memory after completed the printing and turns the electrical power to off.
After finishing to print, cut the printed tape and check that it is 79 ± 4 mm (tape length) and
50.2 +4, -2.5 mm (printed letter length)
9.2.6. PRINT 2 Mode “6” Key
Performs the same printing as PRINT 1.
My be omitted when PRINT 1 is confirmed being correct.
Fig. 19 is displayed when depressed “6” key (except while in the Key Inspection Mode).
Fig. 19
The function is started when depressed “ ” key. The electrical power will not be turned to
off in this case.
F E E D
3
P R N 1
<A Printing Sample>
P R N 2
To Next Page
