Assembly
Type 8228
7.5 Dismounting the display module
20°
→ Remove the cover (see chap. 7.2).
→ Turn the module by ca. 20° counterclockwise.
Once unlocked, the module is raised slightly by the spring
action.
→ Remove the module from its housing.
Fig. 7: Dismounting the display module
