Calix ODC-80 Installation Guide
5
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© 2001-2003 Calix. All Rights Reserved.
Front access
The front of the ODC-80 provides access to the equipment compartments for 4 Calix C7
shelves and power distribution equipment.
Equipment in the front compartment
Equipment in the front compartments of an ODC-80 include:
• AC load center with AC entry
• Optional generator connector
• 4 Calix C7 shelves
• 2 power shelves and rectifiers
• DC distribution panel
Front view of the ODC-80
