16
Calix ODC-80 Installation Guide
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© 2001-2003 Calix. All Rights Reserved.
What you get with the cabinet
Items in the installation kit
The following items are shipped inside the battery tray of the ODC-80 as an installation kit:
• Calix coffee cup with lid (quantity 2)
• 2-inch cold shrink tubing (quantity 4)
• 4-inch cold shrink tubing (quantity 4)
• cable management posts for use in the cable splice compartment (quantity 12)
• allen wrench for cable management post installation, T-handle
(quantity 1)
• allen wrench for roof access, T-handle, 5/16-inch ball end (quantity 1)
• cable entry plate, 4-inch (quantity 4)
• cable entry plate containing two 2-inch feed tubes (quantity 2)
• security hex key for door access, 8mm (quantity 1)
• brackets for holding third-party rack mount fiber and cable management
accessories (quantity 2)
• seismic battery kit
• pad mount hardware kit
• fiber strain relief
• Labels for identifying T1 slots on the copper protection panels (4 sheets)
• Miscellaneous hardware and tie wraps
Items in the optional battery string kit with batteries
• string of 4 Dynasty 12 Volt 125AH batteries
• battery wiring kit for Dynasty batteries (white wire jumpers, pre-terminated)
• No-Ox grease for use on battery terminals
• set of four battery lifting straps
Items in the optional battery string kit without batteries
• battery wiring kit for Dynasty batteries (white wire jumpers, pre-terminated)
• No-Ox grease for use on battery terminals
