76
Calix ODC-80 Installation Guide
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© 2001-2003 Calix. All Rights Reserved.
Battery circuit breaker alarm
Alarm output
When the alarm occurs, the following message displays:
TID-000 01-09-10 09-15-00
* 001 REPT ALM ENV
"N2-1:MN,BATTCB,NSA,9-10,9-15-00,NEND;"
Clearing output
You will see this message once the alarm has been cleared from the system.
TID-000 01-09-10 09-20-00
A 001 REPT EVT ENV
"N2-1:BATTCB,CL,9-10,8-15-00;"
Description Severity
The battery circuit breaker (BATTCB) alarm indicates that one or both of
the circuit breakers in the battery compartment has failed.
The BATTCB alarm will occur as a result of a either battery or rectifier
malfunction. A circuit breaker failure is caused by an over amperage
condition.
Minor
