Rectifier minor alarm
Alarm output
When the alarm occurs, the following message displays:
TID-000 01-09-10 16-15-00
* 001 REPT ALM ENV
"N2-1:MN,RECT,NSA,9-10,15-15-00,NEND;"
Clearing output
You will see this message once the alarm has been cleared from the system.
TID-000 01-09-10 16-15-00
A 001 REPT EVT ENV
"N2-1:RECT,CL,9-10,16-15-00;"
Description Severity
The rectifier minor (RECT) alarm indicates that the outdoor cabinet
rectifier shelf has a minor alarm. The RECT alarm is always reported
as a minor alarm.
Minor
