84
Calix ODC-80 Installation Guide
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© 2001-2003 Calix. All Rights Reserved.
Rectifier major alarm
Alarm output
When the alarm occurs, the following message displays:
TID-000 01-09-10 15-15-00
** 001 REPT ALM ENV
"N2-1:MJ,RECT,NSA,9-10,15-15-00,NEND;"
Clearing output
You will see this message once the alarm has been cleared from the system.
TID-000 01-09-10 15-15-00
A 001 REPT EVT ENV
"N2-1:RECT,CL,9-10,15-15-00;"
Description Severity
The rectifier major (RECT) alarm indicates that the outdoor cabinet
rectifier shelf has a major alarm.
The Calix rectifier will report a major alarm for high voltage shut down,
AC fail, Fuse Alarm, and low voltage disconnect.
Major
