Calix ODC-80 Installation Guide
43
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© 2001-2003 Calix. All Rights Reserved.
Installing Outside Plant Cables
Subscriber cables
Route copper subscriber cables into the copper splice compartment on the left side of the
ODC-80 then terminate the cables to the factory installed equipment cables.
Install copper protection modules in the copper protection compartment at the rear of the
cabinet.
Note
You can route subscriber cable through any one of the cable
entry locations. For best results with a high copper count
configuration, route the cable to the right.
