Outdoor cabinet fan tray filter description
Install the filter after the fan tray has been installed. The filter used in outdoor cabinets
contains no filter element but is required to provide EMI suppression.
Procedure to install the shelf filter
Step Action
1.
If you have not already done so, remove the filter from its packaging.
2.
Lift the fan tray handle up to disengage its locking mechanism, and rotate it
out to its upright and locked position. Do not remove the fan tray.
3.
Insert the filter into its slot below the fan tray with the "Airflow" label text on
the front edge of the filter in the upright position facing you. Push the filter
into place.
4.
Push in on the fan tray handle and rotate down to lock the fan tray into
position. (Note: In the locked position, the handle should be flush with the
bottom lip of the shelf.)
