Procedure to install an optical plug-in card
Step Action
1.
If you have not already done so, remove the optical card from its packaging
and remove the plug cover at the rear of the card.
2.
Pull the card ejector down to the unlocked position.
3.
Slide the card along the guide rails into any universal slot. Important: To
avoid causing damage to the card or the shelf, align the card correctly
with the guide rails prior to inserting it.
4.
Push the card ejector up into the locked position.
5.
Remove the fiber protector cover from the top front of the card.
6.
Identify the appropriate fiber cable assignments for each optical card (from
the labels applied when you dressed the fiber cables earlier in the installation
process).
7.
Beginning with port 1 at the top of each card, insert the appropriate LC
connector with the key turned to the right into the face of the card. (Note:
the Calix optical card ports are located on the face of each card and are
numbered from the top of the card down -1, 2, 3, etc. - with the RX connector
in the front and the TX connector immediately behind it.)
8.
After terminating all the appropriate LC connector ends into the optical card,
replace the card's fiber protector cover.
9.
Repeat steps 1 through 7 for each optical card.
