F 7 (Command 2-7): setting the 2-7 contact to either the step (open-close) or sequential (open-stop-close-stop) modes.
0 = step-step (default); 1 = sequential.
F 8 (Command 2-3P): setting contact on 2-3P to pedestrian opening (total opening of the second leaf) or partial (partial opening of the second leaf
depending on p
ercentage setting between 10 and 80 of the travel, feature F 36).
0 = pedestrian opening (default); 1 = Partial opening.
F 9 (Obstacle detection): with motor idle (gate closed, open or after a total stop command), it prevents any movement if the safety devices (e.g.
cells) detect an obstacle.
0 = Deactivated (default); 1 = activated.
1 = - 1 = - gate is opening, it flashes intermittently each half-second;
- gate closing, it flashes intermittently each second;
- gate open, stays lit;
- gate closed, stays off.
F 11 (Encoder exclusion): excludes management of the slow downs, obstacle detection and sensitivity.
0 = E
ncoder activated. (default); 1 = Encoder deactivated.
F 10 (Open signal-light): Light bulb connected to 10-5, signals gate status.
F 14 (Sensor type): setting the sensor-type for the operator command via TSP00 transponder or LT001 magnetic card reader with the R700 coding
board or S70
00 keypad with R800 coding board.
0TAG; 1 = S7000 (default).
F 16 (Ramming): before each opening and closing manoeuvre, the leaves press against the strike-plate for a few seconds to facilitate the electro-lo
ck
release (to adjust the time, see feature F26).
0 = deactivated (default); 1 = activated.
0 = gate open or moving, stays lit (default)
