2.0 06/2012 © CAME Cancelli Automatici S.p.A. - The data and information in this manual may be changed at any time and without obligation on the part of Came Cancelli Automatici S.p.A. to notify said changes.
ENGLISH
F 19 (Automatic closing time): The automatic closing timer activates at the closing endpoint. The pre-set time is adjustable, and is anyhow conditio-
ned by a possible intervention by the safety devices and is deactivated after a total emergency stop or when the power is cut.
The waiting time can be deactivated or adjusted from 1" to 180".
= 0 = Deactivated (default); 1 = 1 second; 2 = 2=seconds; .................. 180 = 180=seconds.
F 20 (Automatic closing time after partial or pedestrian opening): leaf automatic closing time after a partial or pedestrian opening command.
The d
oor closes automatically once this time-frame has elapsed and is anyway subject to the trigger of any safety devices and it deactivates after a
«total emergency stop" or due to power outages . The waiting time can be adjusted from 1" to 180”
Note: the automatic closing time (see F 19) should not be deactivated.
1 = 1 second; 2 = 2=seconds; .................. 5 = 5=seconds (default); .................. 180 = 180=seconds.
F 21 (Pre-flashing time): after an opening or closing command, the flashing light connected on (10-E), flashes for an adjustable time interval before
the mano
euvre begins.
the pre-flashing time can be deactivated or adjusted from 1" to 10".
= 0 = Deactivated (default); 1 = 1 second; 2 = 2=seconds; .................. 10 = 10=seconds.
F 22 (Working time): motor operation time in when opening or closing.
the wo
rking time can be adjusted to between 5" and 120"
5 = 5=(seconds; .................. 120 = 120=(seconds (default).
F 23- (Opening delay time): after an opening command, the leaf of gearmotor (M1) starts moving after that of gearmotor (M2) and the time is adju-
stabl
e.
the delay time can be deactivated or adjusted from 1" to 10".
= 0 = Deactivated (default); 1 = 1 second; 2 = 2=(seconds .................. 10 = 10=seconds.
F 18 (Light W-E): output on contact W-E for the light with the following feature:
- movement war
ning flashing light, flashes while gate is opening and closing.
- outdoor freely placeable light, to enhace lighting in the parking area, set as courtesy light which stays lit for a set time of 180 seconds or as a cycle
light that stays on from the moment the leaf starts opening until it is completely closed (including automatic closing time) .
0 = Flashing light (by default); 1 = Cycle; 2 = Courtesy.
