2.0 06/2012 © CAME Cancelli Automatici S.p.A. - The data and information in this manual may be changed at any time and without obligation on the part of Came Cancelli Automatici S.p.A. to notify said changes.
ENGLISH
F 38 (Closing slow down point): adjusts the motor's beginning slow down point before the closing endstop.
the beginning deceleration point is calculated as a percentage of the leaf's complete travel (see par. illustration of slow down and end strike areas and
points )
10 = 10% of the travel; .................. 25 = 25% of the run-cycle (default); .................. 60 = 60% of the run-cycle.
F 39 (Opening end-strike point): adjusts the starting point of the motor's end-strike before the opening endstop.
the b
eginning end-strike point is calculated as a percentage of the leaf's complete travel. (see par. illustration of slow down and end strike areas and
points )
1 = 1% of the travel; .................. 5 = 5% of the run-cycle (default); ..................10 = 10% of the run-cycle.
F 40 (Closing end-strike point): adjusts the starting point of the motor's end-strike before the closing endstop.
the b
eginning end-strike point is calculated as a percentage of the leaf's complete travel (see par. illustration of slow down and end strike areas and
points )
1 = 1% of the travel; .................. 5 = 5% of the run-cycle (default); .................. 10 = 10% of the run-cycle.
F 46 (Number of motors): setting the number of motors connected to the control panel.
0 = Ena
bling both motors (M1+M2) (default); 1 = 2 = Enabling just one motor (M2)
F 50 (Save data): saves users and all settings in the memory roll.
Not
e: this feature appears only if the memory roll is plugged into the mother board.
= 0 = Deactivated; 1 = activated
F 51 (Data reading): loads memory roll data onto the mother board.
Not
e: this feature appears only if the memory roll is plugged into the mother board.
= 0 = Deactivated; 1 = activated.
