4- 28
îš‹ Replacing the Printhead
TOP
Chapter 3
Printing Methods for
Different Objectives
Chapter 4
Maintaining the
Printer
Chapter 5
Using the Printer in a
Network Environ-
ment
Chapter 6
Troubleshooting
Chapter 7
Operation of the
Function Menus
Index
Contents
Chapter 2
Using a Variety of
Media
Chapter 1
Basic Procedures
15
Push the printhead lever toward the back of
the printer and down, then press down until
you hear it click and lock.
16
Lower the carriage cover and press down
until you hear it click and lock.
17
Raise the upper cover stopper to release the
lock then close the upper cover.
As soon as you close the upper cover of the printer,
Please Wait.. is displayed in the bottom line of the
display and processing begins. The processing
requires about 10 minutes to complete.
As soon as processing is finished, Advanced Adj. is
displayed and the printhead is adjusted
automatically. (→ P. 4- 4 0)
Important
z The printhead adjustment does not execute if the Auto
Print feature on the Main menu is set to Off. After
replacing the printhead, perform Advanced Adj. under
Auto Head Adj. on the printer operation panel to
adjust the printhead automatically. (→ P. 4 -4 0 )
z The printhead adjustment cannot be performed if the
loaded roll paper or cut sheets are not at least A3 (L)
size or larger. Printhead adjustment continues as soon
as the media is set.
z Never attempt to remove an ink tank when the ink
tanks are filling during the installation procedure and
immediately after replacing the printhead, or during the
printer cleaning operation.
To Next Page
