Aligning the Printhead
If printed vertical lines are bent, or if the colors are faded
and uneven, perform the printhead position adjustment.
The printer will adjust the position of the printhead
automatically as it reads the pattern used to adjust the
position of the printhead. Before you adjust the position of
the printhead, make sure a roll or cut sheets A3 (L) size or
wider are loaded in the printer.
Use the following procedure to adjust the position of the
printhead.
Note
z When you adjust the printhead, you should use the
media of the type (other than film) that you use most
frequently.
z If you are using cut sheets, make sure at least one
sheet of unused A3 paper (not the blank sides of used
paper) or larger are set.
Aligning Printhead Procedure
1
If the printer power is off, press the Power
button to switch the printer on.
Within a short time, Online or Offline is displayed.
2
Press the Online button to display MAIN
MENU.
3
Press [] or [] to select Adjust Printer,
then press [
].
4
Press [] or [] to select Auto Head Adj.,
then press [
].
MAIN MENU
Adjust Printer ↓
Adjust Printer
Auto Head Adj. ↓
Data
Information Power
Offline
Menu
Message
Online
Cleaning
(3 sec.)
Stop/Eject
(1 sec.)
MAIN MENU
Head Cleaning
Online
Cleaning
(3 sec.)
Stop/Eject
(1 sec.)
To Next Page
