2- 30
îš‹ Printing with Rolls
TOP
Chapter 3
Printing Methods for
Different Objectives
Chapter 4
Maintaining the
Printer
Chapter 5
Using the Printer in a
Network Environ-
ment
Chapter 6
Troubleshooting
Chapter 7
Operation of the
Function Menus
Index
Contents
Chapter 2
Using a Variety of
Media
Chapter 1
Basic Procedures
8
While gently pulling out the center of the
leading edge (e) of the roll media, align the
right edge of the media so it is parallel to
guideline (f), then pull the release lever to the
front to close it.
Important
z Do not pull strongly the roll media when you align it
with the guideline. The roll media may not feed out
straight in some cases.
9
Raise the upper cover stopper to release the
lock then close the upper cover.
Media Type is displayed.
10
Press [] or [] to select the loaded media
type, then press OK.
The (=) mark to the left of a setting indicates that roll
media type is currently selected, then the
preparation for the select media begins.
The table below lists the settings for the media
types. Only the types of media that can be used with
the black ink tank installed in the printer are
displayed.
e
Media Type
HW Coated
Media Name Media Type Setting
Plain Paper Plain Paper
CAD Plain Paper CAD Plain Paper
Plain Paper (High Quality) Plain Paper HQ
Recycled Coated Paper Recycled Coated
Coated Paper Coated Paper
Heavyweight Coated Paper HW Coated
Premium Matte Paper Premium Matte
Extra Heavyweight Coated
Paper
Ex HW Coated
Glossy Photo Paper Glossy Photo
SemiGlos Photo Paper Semi-Gl Photo
Heavyweight Glossy Photo
Paper
HW Glossy Photo
Heavyweight SemiGlos
Photo Paper
HW SemiGl Photo
Synthetic Paper Syn. Paper
Adhesive Synthetic Paper Adh. Syn. Paper
Backlit Film Backlit Film
Flame-Registrant cloth Flame-Res.Cloth
To Next Page
