Canon iPF9000S - Page 101

Chapter 4 More Sophisticated Fault Isolation Tasks
3-27
Explanatory drawing 4
abcd e f g
Symbol Width
a About 32 mm
b About 40 mm
c About 135 mm
d About 40 mm
e About 180 mm
f About 40 mm
g About 135 mm
Paper
Platen
Suction
Explanatory drawing 3
Head
Non-uniform colors
Print misregistration
Explanatory drawing 2
Suction
Platen
Head
Paper
Explanatory drawing 1
Vertical
Horizontal
Direction of Lines
