Chapter 5 Fault Isolation Tool Collection

4-29

Display

position

Explanation Target series

① Roll path sensor 0: Sensor on, 1: Sensor off 5000

② Roll cam sensor 0: Sensor on, 1: Sensor off 5000

③ Cutter lift sensor 0: Sensor on, 1: Sensor off 5000

④ Cutter right edge sensor 0: Sensor on, 1: Sensor off 5000/650/750/800

⑤ Cutter left edge sensor 0: Sensor on, 1: Sensor off 5000/650/750/800

⑥ Carriage HP sensor/Lift cam sensor 0: Sensor on, 1: Sensor off 700/650/750/800/8000

⑦ Pressure release sensor 0: Pressure release, 1: Pressure 700/800/8000

⑧ Paper sensor 0: Paper not available, 1: Paper available 700/650/750/800/8000

⑨ Roll Paper rotation detection sensor 0: Sensor on, 1: Sensor off 8000

⑩

Roll unit detection

0: Roll Paper unit not available,

1: Roll Paper unit available

5000

⑪

Cutter unit detection

0:Cutter unit not available

1: Cutter unit available

5000

⑫

Paper take-up unit mount detection

0: Paper take-up unit not available,

1: Paper take-up unit available

800/8000

⑬ Paper take-up unit sensor 0: Sensor on (low), 1: Sensor off (high) 800/8000

⑭ Ink valve open/close sensor L 0: Sensor on, 1: Sensor off 700/650/750/800/8000

⑮ Air-through valve open/close sensor R 0: Sensor on, 1: Sensor off 650/750/800

I/O DISPLAY 2

⑯ Air-through valve open/close sensor L 0: Sensor on, 1: Sensor off 650/750/800

Display

position

Explanation Target series

① Release lever lock sensor 0: Sensor on, 1: Sensor off 650/750

②

Pinch roller pressure release detection

switch

0: Pressure release, 1: Pressure 650/750

③ Shutter HP sensor 0: Sensor on, 1: Sensor off 650/750

④ （Not used） Common

⑤ （Not used） Common

⑥ （Not used） Common

⑦ （Not used） Common

⑧ （Not used） Common

⑨
