Chapter 6 Miscellaneous Information
5-3
（b） カウンタ情報
■定期交換部品／消耗部品のカウンタ（iPF700 の例）
■Periodically replaced/consumable parts counter (iPF8000 example)
PARTS COUNTER
COUNTER A : OK 703
PARTS A1 : 66.5 428.6 15% 66.5
PARTS A2 : 3.0 233.3 1% 3.0
COUNTER D : OK 703
PARTS D1 : 494227 11333333 4% 494227
PARTS D2 : 429867 14100000 3% 429867
PARTS D3 : 390 4550 8% 390
COUNTER F : OK 703
PARTS F1 : 119067 3740000 3% 119067
COUNTER H : OK 703
PARTS H1 : 3507 50000 7% 3507
COUNTER K : OK 703
PARTS K1 : 155 6000 2% 155
COUNTER M : OK 703
PARTS M1 : 44 1500 2% 44
PV AUTO JUDGE : ON(NORMAL) , 1
Ink saving mode ON/OFF indication
ON indicates either Normal or Low.
The value indicates the number of times
entered.
COUNTER A: Waste ink absorber
Count (dot count mL)
D1: CR bearing
Count (reading ×210 mm)
D2: Encoder sensor
Count (Total ink ejection rate in multiples of one
million dots)
D3: Carriage height changing cam
Count (rotation count)
F1: Ink supply system (tube, flexible cable)
Count (CR scan count)
H1: Purge unit
Count (controller cam rotation count)
K1: Non-ejection unit
Count (non-ejection operation count)
M1: CR motor
Count (CR drive time h)
⑤
⑥
④
② ①
③
PARTS COUNTER
COUNTER A : OK 682
PARTS A1 : 9.7 3028.6 0% 9.7
PARTS A3 : 26.8 890.5 3% 26.8
PARTS A4 : 1.5 890.5 0% 1.5
PARTS A5 : 0.4 651.4 0% 0.4
PARTS A6 : 65.9 666.7 9% 65.9
COUNTER D : OK 682
PARTS D1 : 1068174 33333333 3% 1068174
PARTS D2 : 800422 48000000 1% 800422
PARTS D3 : 3242 60000 5% 3242
PARTS D4 : 247999 7360000 3% 247999
COUNTER H : OK 682
PARTS H1 : 4691 50000 9% 4691
COUNTER K : OK 682
PARTS K1 : 178 50000 0% 178
COUNTER M : OK 682
PARTS M1 : 91 3400 2% 91
COUNTER P : OK 682
PARTS P1 : 19869 285714 6% 19869
COUNTER V : OK 682
PARTS V1 : 9.6 2706.7 0% 9.6
① Status indication corresponding to Status
counts (OK, W1, W2, E)
② Number of days elapsed after setting
③ Count
④ Durability value (equivalent to a threshold that
determines W2/E)
⑤ Usage ratio (count ratio to the durability value)
⑥ Cumulative count
D4: Tube unit
Count (CR scan count)
D5: Multisensor
※ iPF9100/9000S/8100/8000S/820/810/
6200/6100/610/605/5100/510
Count (Total ink ejection rate in multiples of one
million dots)
P1: LF adjustment
Count (feeding direction: reading x 210 mm)
V1: Mist collection duct
Count (dot count mL)
HEAD
HEAD DOT CNT.1 C :26747 M :28070 Y :35399
MBK :33077 MBK2:33090 BK :14766
TTL:171152
HEAD DOT CNT.2 C :68870 M :67817 Y :78644
MBK :87470 MBK2:87533 BK :39530
TTL:429867
Current head dot count
Cumulative head dot count
