Troubleshooting Guide
5-4
■Periodically replaced/consumable parts counter (iPF5000 example)
■Other display items (iPF8000S example)
Calibration History (Last 20times)
Date Action Media Temp[C]/Humid[%]
1: 2008/08/18 0
2: 2008/08/06 0
3: 2008/08/04 2 Glossy Photo 25/ 57
Multi Sensor
Unit Ver : 01
DATA :
02 55 20 07 05 08 16 25 01 00 00 00 00 00 00 00
20 81 dc 01 02 81 a8 01 02 81 7c 01 02 01 03 00
CR REG
C2
15 9 5 2 1 -1 -2 -3 -2 -2 0 2 4 5 7 7
8 9 10 11 12 12 12 11 10 9 8 7 6 5 5 4
3 1 0 -2 -4 -4 -4 -3 -1 2 0
BK
12 9 7 5 4 3 2 1 1 2 3 4 5 6 7 7
8 9 10 11 11 12 11 11 10 9 8 7 7 6 6 5
5 4 2 1 -1 -2 -2 -1 0 3 0
C
-6 -5 -4 -4 -4 -3 -2 -2 -1 -1 -1 -2 -2 -3 -3 -3
-3 -3 -3 -4 -4 -4 -4 -4 -4 -4 -4 -3 -3 -3 -3 -2
-2 -2 -2 -1 -1 -1 -1 0 0 0 0
PARTS COUNTER
COUNTER A : OK 796
PARTS A1 : 0.0 36.1 0% 0.0
COUNTER B : OK 796
PARTS B1 : 0.0 48.3 0% 0.0
COUNTER D : OK 796
PARTS D1 : 179143 13028571 1% 179143
PARTS D2 : 97344 6700000 1% 97344
PARTS D3 : 158057 16500000 0% 158057
PARTS D4 : 4733 60000 7% 4733
COUNTER F : OK 796
PARTS F1 : 97344 4000000 2% 97344
COUNTER H : OK 796
PARTS H1 : 2586 50000 5% 2586
COUNTER L : OK 796
PARTS L1 : 111 12500 0% 111
COUNTER P : OK 796
PARTS P1 : 6 750 0% 6
COUNTER Q : OK 796
PARTS Q1 : 1572 27500 5% 1572
COUNTER R : OK 796
PARTS R1 : 1697 27500 6% 1697
COUNTER V : OK 796
PARTS V1 : 0.0 15.2 0% 0.0
B1: Platen duct
Count (dot count mL)
L1: Non-discharging unit
Count (non-ejection count)
Q1: Cassette pickup roller
Count (Cassette pickup count)
R1: Spur lift cam
Count (Total paper feed count)
V1: Mist collection system
Count (dot count mL)
Calibration history
(iPF9100/9000S/8100/8000S/6200/6100/6000S/5100 only)
Up to 20 cycles printed (or as many as there are histories if
less than 20 cycles)
Date/Action/Media/Temp/Humid
(iPF9100/9000S/8100/8000S/6200/6100/6000S/5100 only)
If the multisensor has been replaced, the new unit version
prints in the Media field (00/01).
The contents of the first 32 bytes of EEPROM also print.
Unit Ver/DATA
CR REG adjustment values (iPF8000/8000 Series only)
iPF8000S, iPF9000S: C2/BK/C
iPF8000, iPF9000： B/M/Y
※All values appear as 0 if CR_REG is yet to be executed.
